John Deere Implement Detection
With John Deere Implement Detection, all of the settings used from the previous year or the factory-installed settings on new machines will automatically enter into the GreenStar 3 2630 Display simply by connecting the implement to the tractor. This technology eliminates the need to spend time taking measurements and trying to remember how the implement was setup last year.
How it works
When an implement with Implement Detection is connected to a tractor utilizing a GreenStar 3 2630, a notification will be populated informing the operator that an implement is now on the CAN Bus. The one-page notification will indicate the implement's name, connection type, and other settings saved to the implement controller.
The notification will address each individual setting showing the operator whether the implement settings successfully transferred to the 2630 or not. From this notification, users have the option to accept settings and move to the run page, or they can select the Equipment soft key that takes them to the equipment setup page so they can make adjustments to implement settings if necessary.
All changes to implement settings will override previous settings and will be stored to the controller. If the implement is moved between tractors or displays switched, the implement settings are automatically sent to the display once the ISO connector is reconnected.
Populated settings of the implement on the GreenStar 3 2630 Display
| Required implement information |
Implement Detection |
| Type |
X |
| Model |
X |
| Name |
X |
| Connection type |
X |
| Widths |
X |
| GPS offsets |
X |
| Track spacing |
X |
John Deere Implement Detection provides a Green-on-Green advantage that addresses the single-most frustrating issue in the world of precision agriculture today - usability. Implement Detection will allow John Deere precision technology users to spend more time working and less time setting up their equipment. Enhancements such as this also begin to eliminate the mistakes made by operators in the field as well as reduce the dependence on others to help get the equipment setup like it was the prior year.
Producers with non-John Deere implements can still see the benefits of John Deere Implement Detection when paired with a GreenStar 3 2630 Display and an independent Implement Detection controller. John Deere Implement Detection is designed to be paired with equipment not currently utilizing a controller; such equipment includes tillage implements, planter/seeders, dry-box fertilizer spreaders and sprayers.
NOTE: Implement Detection is not compatible with AccuDepth™.
