Gathering chains designed for increased life
Knife stalk rolls result in better stalk control
AutoTrac™ RowSense™
Single-point latching system is fast and easy

BROCHURE

Features

Features

Expand All Collapse All

RowMax™ stalk roll options for a variety of customer needs

Customers have asked for stalk rolls to appropriately size residue for their operation while managing power and overall header weight.

John Deere offers RowMax stalk rolls to address customer needs around residue, power, and weight for their front-end equipment.

RowMax stalk roll features and benefits:

RowMax stalk rolls can improve wear life by 25 to 30 percent compared to the 600C base stalk rolls.
Three stalk roll options allow customers to select the appropriate length of corn stalk residue.
To provide high performance during harvest, RowMax stalk rolls are designed with reduced power and fuel consumption in mind.
RowMax Chopping Stalk Roll drops stalk residue on top of the row for improved planting performance for no-till and strip-till customers the following season. Additionally, the chopping stalk roll blossoms the top of the stalk for reduced tire and track damage.

Stalk residue dropped on top of the row

Top of the stalk is blossomed

RowMax stalk roll details:

The stalk rolls are manufactured from highly durable austempered ductile iron material with an added wear coating for increased wear life.
The full-length blades provide total crop contact for appropriate sizing and cutting action from front to back.
Stalk roll tip speed compared to gathering chain speed is optimized to reduce material-other-than-grain (MOG) intake and increase overall capacity while minimizing losses.
Enclosed chain drives gathering chains and stalk rolls for each row to provide robust durability and uninterrupted harvesting.
Single-piece cast knife roll design provides excellent serviceability when replacement is required.

Row-unit

Single-piece cast knife roll

Choosing the correct RowMax stalk roll

Stalk rolls without StalkMaster™ corn heads	RowMax Opposed	RowMax Intermeshing	RowMax Chopping
Knife alignment
Residue size	Good	Good	Better
Residue breakdown	Fast	Faster	Fastest
Soil warm up/dry down	Fast	Faster	Fastest
Wear life	Better	Better	Best
Row unit power consumption	Best	Better	Better
Fuel consumption	Best	Better	Good
Trash intake	Best	Better	Better
Dry stalks	Best	Good	Good
Wet stalks	Best	Better	Better
Down corn	Best	Good	Good
Weight for two stalk rolls	17.2 kg (38 lb)	18.1 kg (40 lb)	19.5 kg (43 lb)
StalkMaster with RowMax opposed stalk roll
Residue size	Best
Row unit power consumption vs. opposed without StalkMaster	Good
Weight	Additional 19.1 kg (42 lb) per row for StalkMaster components
General stalk roll parts information
Number of knives	8	6	10
*Aftermarket part numbers (left hand)**	HXE110671	HXE110675	HXE141569
*Aftermarket part numbers (right hand)**	HXE110672	HXE110676	HXE141570
Compatibility	Model year 2012 and newer 600C/600FC and 700C/700FC for StalkMaster and non-StalkMaster row units; factory-installed option code for model year 2020 Corn Heads

*NOTE: Part numbers are subject to change. Please check the parts order before completing the transaction.

RowMax™ row-unit kit for 700C/FC and 600C/FC Corn Heads

The 700C/FC Corn Head RowMax row-unit provides customers increased durability and longer wear life. RowMax row-units include updates to gathering chains, gathering chain sprockets, chain guides, and stalk rolls. These improvements extend the life of the corn head for lower ownership cost.

Feature benefit:

Increased wear life of row-unit gathering chains and sprockets by 50 percent due to solid alloy pin bushings and increased number of sprocket teeth
Increased wear life of stalk rolls up to 30 percent with an improved wear coating
Maintain corn head performance durability with an increase in stalk roll material hardness

RowMax row-unit

Gathering chain and sprocket

Functionality:

To extend the life of the corn head, the RowMax row-unit increases the number of sprocket teeth on gathering chains from six teeth to eight teeth. The gathering chain has an additional 12 links and an anti-bend back feature on the chain lug. Gathering chain wear is reduced by using a solid alloy bushing.

StalkMaster™ row-unit enables a high level of stalk residue processing

StalkMaster row-unit

Available as an option, StalkMaster provides ultimate stalk sizing by processing stalks smaller than stalk rolls allowing the operator to potentially eliminate second-pass operations, saving time, fuel, labor, and additional operating costs.

Feature benefit:

Consistent sizing of corn stalks to speed up decomposition and provide soil protection from blowing wind and water runoff
StalkMaster can be equipped with either intermeshing, opposed, or chopping stalk rolls
Ultimate flexibility to chop or not chop when desired through a quick, no-tools-required disconnect feature

Functionality

StalkMaster blades

Each StalkMaster row-unit gearcase is equipped with two heat-treated and wear-coated rotating blades positioned below the stalk rolls. The blades can be reversed to extend their wear life. These blades cut stalk to size and distribute residue evenly throughout the row. If the blades encounter an obstruction they will swing backward, avoiding damage and interruption to harvest.

StalkMaster disconnect feature

The StalkMaster row-unit gearcase feature a no-tools-required disconnect. Each row has a lever on the right side of the gearcase to turn the function on or off in a matter of minutes if desired, allowing for lower fuel consumption.

StalkMaster gearcase

A heavy-duty slip-clutch design protects the row-unit gearcase and the StalkMaster lower unit gearcase.

712C right-hand side and drive shaft

The gathering chains and stalk rolls for each row are enclosed to provide robust durability. Heavy-duty bearings along with O-ring seals improve serviceability.

Larger sprockets and chain

A continuous-loop chain allows higher loads and longer life by eliminating all connector links and half links. The large-diameter sprockets along with a large 38-mm (1.50-in.) transverse hex back shaft and row-unit shaft provide improved sprocket and chain.

Telescoping drive shaft

A telescoping drive shaft mounts to the splined feederhouse back shaft on all 50, 60, 70, W-, T-, C-, and S-Series Combines.

The coupler features an 8-degree index, allowing the customer to match the drive shaft splines without rotating the platform feederhouse.

Telescoping drive shafts can be retrofitted to earlier 90 Series and 40 Series Corn Heads.

Rubberized curtains

Steel-protective shield

StalkMaster row units feature side- and rear-mounted rubberized curtains to optimize residue distribution. The right-hand side of the head has an additional shield to protect customers from protruding blades.
